Swing gate 3m TRIGLAV H.160cm grey aluminium
- Width: 305cm and Height: 161cm
- For a unique, geometric entrance
- Corrosion resistant
- Accessories included
By validating your purchases, you will be debited for the amount of your order
In reservation
Total before discount
€
Code
- €
Discount
- €
Total to pay (incl. VAT)
€
or
Save 49 €
Save 168 €
Save 99 €
Save 49 €
Save 168 €
Save 99 €
Save 109 €
-5%
between 0 € and 1499.99 €*
-7%
between 1500 € and 2999.99 €*
-10%
greater than 3000 €*
*HT orders
Wind resistance
55 km/h
Compatible pillar spacing
301,5 - 307,5 cm
Height
161 cm
Width
300 cm
Main material
Aluminium
Colour
Charcoal grey
RAL
7016
Finishing
Powder coating
Type of filling
half openworked
Pattern / Design
Honeycomb
Wind resistance
55 km/h
Compatible pillar spacing
301,5 - 307,5 cm
Height
161 cm
Width
300 cm
Main material
Aluminium
Colour
Charcoal grey
RAL
7016
Finishing
Powder coating
Type of filling
half openworked
Pattern / Design
Honeycomb
Opening system
Swing gate
Opening direction
To the house
Compatible engines
Yes
Compatible motorization type
With articulated arm and jacks
Frame material
Aluminium
Width between pillars
305 cm
Minimum pillar height
175 cm
Operating clearance
30 mm
Pivoting system
Ball bearing
Blade section
160*15 mm
Thickness of the blades
1.2 mm
Amounts Section
78*47 mm
Stud thickness
1.5 mm
Sleeper Section
70*30 mm
Sleeper thickness
1.3 mm
Stud/rail assembly
Self-tapping screws
Locking system
Cylinder lock
Handle material
Aluminium
Handle colour
Black
Type of lock
Keys (5)
Rod assembly
Self-tapping screws
Supplied accessories
Yes
Number of upper hinges
2
Number of lower hinges
2
Central stop
Yes
End stop
2
Top cover cap
Yes
Assembly instructions
Yes
Assembly time
8 h
Recommended number of persons for assembly
2
Warranty
2 an(s)
Eligibility Extended warranty 5 years
No
Eligibility Extension of warranty 10 years
No
Available in sliding
Yes
Weight of package No.1
25.2 kg
Weight of package No.2
23.6 kg
Weight of package No.3
6.0 kg
The TRIGLAV swing driveway gate with its graphic design will bring modernity and elegance to your entrance thanks to its unique decorative panels with their "Geometric" style patterns
Description : Modern swing gate with vertical decorative panels
Material : Aluminium
Colour : Anthracite Grey (RAL 7016)
Type of pattern : "Geometric"
Dimensions : Width 300 cm x Height 161 cm
Required width between pillars : 305 cm
Minimum height of pillars : 175 cm
Inspired and designed in France
This do-it-yourself modern double gate kit with laser design contains ::
- 16 powder coated slats (Height 16 cm)
- 2 reinforced powder coated slats for motorisation (Height 16 cm)
- 2 decorative aluminium panels with "Geometric" pattern (Thickness 20/100)
- 2 upper hinges
- 2 bottom hinges
- 1 central stop
- 2 reception stops
- 1 sash lock
- 1 double handles (Black colour)
- Set of 5 keys
- Finishing caps
- Screws and bolts
If you wish to motorise your double leaves gate, Casanoov suggests packs in the "Swing Gate" category
You will find promotional packs offering you a set consisting of a swing driveway gate of your choice accompanied by the appropriate automation.
In case your installation requires pillars, promotional packages are also available containing a swing driveway gate of your choice, together with two aluminium posts to match the chosen entrance gate.
FYI : The minimum pillar height for this gate is 175cm
The TRIGLAV model is also available in other sizes and colours.
For a harmonious exterior, we propose matching sliding gates, garden gates and fences.
To further adapt your swing gate to your project, all our double gate gates can be cut to width
(For an asymmetrical design for example or a narrower entrance).
And for even more customisation, you can change the direction or position of the decorative plates.
Driveway gate delivered in kit form.
Clear instructions, quick and easy assembly.
You will find all the necessary information about this product in the technical data.
