Swing gate 3,5m ARLBERG H.140cm grey aluminium

Name: Swing gate 3,5m ARLBERG H.140cm grey aluminium
Brand: casanoov
Price: 1539.0 EUR
Availability: InStock

SKU : KIT-000125

1289 €

Enjoy an extra 5% off with code CASA5

code:

Width: 350cm and Height: 145cm
Ideal for a unique, graphic entrance
Corrosion resistant
Accessories included

In stock - Estimated delivery between 21/07 and 24/07
Free shipping

Promotional pack

Save money! Discover the packs associated with this product

CASA5

Electric swing gate 3.5m ARLBERG 350B140 + RANGER B150 motorization 1818 € 1769 €

This motorized gate pack contains:
ARLBERG design swing gate gray
Width 350cm and Height 145cm
Actuator motorization (up to 300kg)

Estimated delivery between 21/07 and 24/07

CASA5

ARLBERG 350B140 swing gate pack + ARLBERG 100P140 Gray gate 1868 € 1819 €

This pack contains:
Gray ARLBERG design aluminum swing gate
Width 350cm and Height 145cm
Gray ARLBERG design aluminum gate

Estimated delivery between 21/07 and 24/07

CASA5

ARLBERG 350B140 swing gate pack + 2 EIFEL posts H.166cm Gray 1867 € 1839 €

This pack contains:
ARLBERG design swing gate gray
Width 350cm and Height 145cm
2 aluminum posts H.166cm gray

Estimated delivery between 21/07 and 24/07

-5%

between 0 € and 1499.99 €*

-7%

between 1500 € and 2999.99 €*

-10%

greater than 3000 €*

*HT orders

Technical data

Compatible pillar spacing

351,5 - 357,5 cm

Wind resistance

55 km/h

Height

145 cm

Width

350 cm

Main material

Aluminium

Colour

Charcoal grey

RAL

7016

Finishing

Powder coating

Type of filling

half openworked

Pattern / Design

Graphic line

Compatible pillar spacing

351,5 - 357,5 cm

Wind resistance

55 km/h

Height

145 cm

Width

350 cm

Main material

Aluminium

Colour

Charcoal grey

RAL

7016

Finishing

Powder coating

Type of filling

half openworked

Pattern / Design

Graphic line

Opening system

Swing gate

Opening direction

To the house, see technical diagram

Compatible engines

Yes

Compatible motorization type

With articulated arm and jacks

Frame material

Aluminium

Width between pillars

355 cm

Minimum pillar height

160 cm

Operating clearance

30 mm

Pivoting system

Ball bearing

Blade section

160*15 mm

Thickness of the blades

1.2 mm

Amounts Section

78*47 mm

Stud thickness

1.5 mm

Sleeper Section

70*30 mm

Sleeper thickness

1.3 mm

Stud/rail assembly

Self-enhancing vis

Locking system

Cylinder lock

Handle material

Aluminium

Handle colour

Black

Type of lock

Keys (5)

Rod assembly

Self-enhancing vis

Supplied accessories

Yes

Number of upper hinges

Number of lower hinges

Central stop

Yes

End stop

Top cover cap

Yes

Assembly instructions

Yes

Assembly time

8 h

Recommended number of persons for assembly

Warranty

2 an(s)

Eligibility Extended warranty 5 years

Eligibility Extension of warranty 10 years

Available in sliding

Yes

Weight of package No.1

27.1 kg

Weight of package No.2

28.0 kg

Weight of package No.3

6.8 kg

Description

Width: 350cm and Height: 145cm
Ideal for a unique, graphic entrance
Corrosion resistant
Accessories included

The ARLBERG swing driveway gate with its graphic design will bring modernity and elegance to your entrance thanks to its unique decorative panels with their "Graphic line" style patterns

Description : Modern swing gate with vertical decorative panels
Material : Aluminium
Colour : Anthracite Grey (RAL 7016)
Type of pattern : "Graphic line"
Dimensions : Width 350 cm x Height 145 cm
Required width between pillars : 355 cm
Minimum height of pillars : 160 cm
Inspired and designed in France

This do-it-yourself modern double gate kit with laser design contains ::
- 14 powder coated slats (Height 16 cm)
- 2 reinforced powder coated slats for motorisation (Height 16 cm)
- 2 decorative aluminium panels with "Graphic line" pattern (Thickness 20/100)
- 2 upper hinges
- 2 bottom hinges
- 1 central stop
- 2 reception stops
- 1 sash lock
- 1 double handles (Black colour)
- Set of 5 keys
- Finishing caps
- Screws and bolts

If you wish to motorise your double leaves gate, Casanoov suggests packs in the "Swing Gate" category
You will find promotional packs offering you a set consisting of a swing driveway gate of your choice accompanied by the appropriate automation.

In case your installation requires pillars, promotional packages are also available containing a swing driveway gate of your choice, together with two aluminium posts to match the chosen entrance gate.
FYI : The minimum pillar height for this gate is 160cm

The ARLBERG model is also available in other sizes and colours.
For a harmonious exterior, we propose matching sliding gates, garden gates and fences.

To further adapt your swing gate to your project, all our double gate gates can be cut to width
(For an asymmetrical design for example or a narrower entrance).

And for even more customisation, you can change the direction or position of the decorative plates.

Driveway gate delivered in kit form.
Clear instructions, quick and easy assembly.
You will find all the necessary information about this product in the technical data.
