- This pack contains:
- ARLBERG 3m aluminum sliding gate
- Width: 390cm and Height: 178cm
- 2 aluminum posts, 240cm high
4m ARLBERG sliding gate, 180cm high, grey aluminum + 2 ELDA grey aluminum posts
PAC-004082
2058 €
- This pack contains:
- ARLBERG 3m aluminum sliding gate
- Width: 390cm and Height: 178cm
- 2 aluminum posts, 240cm high
Secure payment
Delivery within 5 days
Free shipping
4m ARLBERG sliding gate, 180cm high, grey aluminum + 2 ELDA grey aluminum posts
2058 €
-5%
between 0 € and 1499.99 €*
-7%
between 1500 € and 2999.99 €*
-10%
greater than 3000 €*
*HT orders
Description
Sliding gate kit 4m ARLBERG H.180cm grey aluminium
Looking for a unique, designer sliding gate? Discover our ARLBERG range.
Discover the ARLBERG designer sliding gate, with its 'graphic line' patterns that add a bold, modern touch. These geometric cutouts play with the light while ensuring privacy. This sliding aluminum gate combines lightness and …
Set of 2 ELDA posts 15x15cm aluminum H.240cm anthracite gray
The ELDA 15x15cm aluminum posts are designed to offer strength, durability, and elegance for your aluminum gate and pedestrian gate installations. With a total height of 240cm and a thickness of 3mm, these posts guarantee optimal stability for gates up to 160cm high.
Made of …
Sliding gate kit 4m ARLBERG H.180cm grey aluminium
Looking for a unique, designer sliding gate? Discover our ARLBERG range.
Discover the ARLBERG designer sliding gate, with its 'graphic line' patterns that add a bold, modern touch. These geometric cutouts play with the light while ensuring privacy. This sliding aluminum gate combines lightness and strength, offering an ideal solution for those seeking both protection and contemporary aesthetics.
Sliding Gate: Ideal Solution for Small Spaces and Sloping Land
A sliding gate is the perfect choice for optimizing the space in your driveway, especially if it is limited. Thanks to its side opening, it is perfectly suited to situations where a swing gate would be restrictive. It facilitates vehicle passage without requiring any backing up, and can be installed on a sloping driveway. If you want even more convenience, a sliding gate motor allows you to automate its opening, for simpler and more fluid daily use.
This sliding gate has a wind resistance of 55 km/h.
Material: Aluminum
Color: Anthracite Gray - RAL 7016
Pattern: "Graphic Line"
Dimensions: Width 390 cm x Height 178 cm
Total width required with clearance: 832 cm
Minimum pillar height: 190 cm
Inspired and designed in France
- 18 powder-coated slats (height 16 cm)
- 2 reinforced powder-coated slats for motorization (height 16 cm)
- 2 decorative aluminum plates with a "Graphic Line" pattern (thickness 20/100)
- 1 upper guide with 4 nylon rollers
- 8 m steel guide rail
- 4 steel rollers
- 1 receiving strike plate
- 1 receiving stop
- 1 cylinder lock
- 1 handle (black)
- 5 keys
- Finishing caps
- Screws
About the Material
Aluminum is highly resistant to temperature changes, whether hot or cold. It doesn't warp and remains in excellent condition, even after years of use. This robust material is built to last while maintaining its beautiful appearance. With aluminum, you're simply choosing a reliable solution suitable for all conditions.
Need posts?
Posts are not included in our kits, as they are not necessary if you already have exterior pillars or posts for installing your product.
If you need pillars, we offer promotional packs that include the product of your choice with two suitable posts.
To ensure a safe and stable installation of your sliding gate, the posts must be at least 190 cm high and at least 15 cm wide.
How to maintain your aluminum structure?
Aluminum requires little maintenance, but regular cleaning extends its lifespan. Once or twice a year, simply use warm soapy water and a soft cloth, then rinse and dry thoroughly. Avoid abrasive products and high-pressure cleaning, which could damage the lacquer.
Need help choosing your sliding gate?
Contact our customer service via our online form.
Product delivered in kit form
Clear instructions
Quick and easy assembly
Find all the necessary information about this product in the Technical specifications
Download the instructionsSet of 2 ELDA posts 15x15cm aluminum H.240cm anthracite gray
The ELDA 15x15cm aluminum posts are designed to offer strength, durability, and elegance for your aluminum gate and pedestrian gate installations. With a total height of 240cm and a thickness of 3mm, these posts guarantee optimal stability for gates up to 160cm high.
Made of Qualicoat-certified powder-coated aluminum, they are highly resistant to corrosion and weathering. Their anthracite gray color (RAL 7016), with a matte sandblasted finish, harmonizes with all CASANOOV aluminum gates and pedestrian gates for a modern and refined look.
These posts are designed for installation in concrete (without a base plate), ensuring a robust and durable fixing, even for motorized installations.
They are compatible with all our aluminum gates and pedestrian gates up to 160cm, as well as with all CASANOOV motors, for simple and reliable installation.
- 2 aluminum posts
- 2 aluminum post caps
- Galvanized steel screws included
- Clear assembly instructions
Important: This kit does not include a base or mounting plate. It must be set in the ground with a minimum of 50 cm of concrete to ensure maximum stability.
The finishing cap is easy to install and remove, allowing for the passage of electrical cables for motorization or the addition of accessories (photocells, flashing lights, etc.).
Maintenance: Simply cleaning with soapy water is all that is needed to preserve the shine and color of your post.
For this product
Clear instructions
Quick and easy assembly
Find all the necessary information about this product in the Technical specifications
Download the instructionsTechnical data
-
Wind resistance
55 km/h
-
Height
178 cm
-
Width
390 cm
-
Main material
Aluminium
-
Colour
Charcoal grey
-
RAL
7016
-
Finishing
Sand mat
-
Type of filling
half openworked
-
Pattern / Design
Graphic Line
-
Opening system
Sliding
-
Opening direction
left to right / right to left
-
Compatible engines
Yes
-
Compatible motorization type
Sliding
-
Frame material
Aluminium
-
Width between pillars
390 cm
-
Required pillar height
190 cm
-
Operating clearance
26 mm
-
Length of the tail of the sliding gate
25 cm
-
Guide system
Upper guide with 4 nylon olives
-
Required discharge length
4 m
-
Blade width
155 mm
-
Thickness of the blades
1.2 mm
-
Amounts Section
78*47 mm
-
Stud thickness
1.5 mm
-
Sleeper Section
70*30 mm
-
Sleeper thickness
1.2 mm
-
Stud/rail assembly
Self-drilling screws
-
Locking system
Barrel lock
-
Handle colour
Black
-
Handle material
Aluminium
-
Type of lock
5 keys
-
Rod assembly
Self-drilling screws
-
Supplied accessories
Yes
-
Number of casters
4
-
Length of steel rail
8 m
-
Assembly instructions
Yes
-
Assembly time
8 h
-
Recommended number of persons for assembly
2
-
Warranty
2 an(s)
-
Eligibility Extended warranty 5 years
No
-
Eligibility Extension of warranty 10 years
No
-
Exists by beating
Yes
-
RAL
7016
-
Section
15*15 cm
-
Main material
Aluminum
-
Finishing
Powder coating
-
Hat size
15*15 cm
-
Type of installation
To seal
-
Width
15 cm
-
Warranty
2 an(s)
-
Screws included
Yes
-
Height
240 cm
-
Colour
Charcoal grey
-
Mounting plate included
No
-
Notice
Yes
-
Thickness
3 mm
-
Installation type
To be sealed
